RackMount Kit for SonicWall TZ500


RM-SW-T5:

RM-SW-T5

This product is no longer available.

Please Contact us for more information.


All rack mounts are subject to the availability of given stocks and can vary significantly
based on the timing and the size of the order.

The RM-SW-T5 gives you the ability to mount your SonicWall desktop firewalls in a 19" rack. The rack is tailored specifically for the listed models to guarantee a perfect fit. In addition, the connections are brought to the front for easy access. The power supply is fixated to prevent an accidental loss of power.

Assembly will take about 5 minutes. Simply slide your SonicWall device in the kit, place the retainers, connect the supplied cables to the keystones and fix the power supply to the rack.

Image Views:



Specifications
Manufacturer Rackmount.IT
Model Sonicwall
For Use SonicWall TZ500
Color RAL 9005 Jet Black
Height 1U
Dimensions
(height x width x depth)
1.73 in. x 18.98 in. x 8.54 in. (44 x 482 x 217 mm)
Number of connections brought to the front 9
Console port to the front Yes
Cables 9x 0.5m cables
Couplers 9x RJ45 couplers
What's in the box
  • 1x SW-Rack + RJ45 couplers
  • Cables
  • Assembly materials
  • Installation guide

Download the RM-SW-T5 Datasheet (PDF).
